Expansion Slots Direct Media Interface (DMI) Revision: 4;Max # of DMI Lanes: 8;Intel® Thunderbolt™ 4: Yes;Scalability: 1S Only;PCI Express Revision: 5.0 and 4.0;PCI Express Configurations: Up to 1x16+2x4, 2x8+2x4, 1x8+4x4;Max # of PCI Express Lanes: 24
NPU NPU Name: Intel® AI Boost;NPU Peak TOPS (Int8): 13;Sparsity Support: Yes;Windows Studio Effects Support: Yes;AI Software Frameworks Supported by NPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebNN
Graphics GPU Name: Intel® Graphics;Graphics Base Frequency: 300 MHz;Graphics Max Dynamic Frequency: 2 GHz;GPU Peak TOPS (Int8): 8;Graphics Output: DP 2.1 UHBR20, HDMI 2.1 FRL, eDP1.4b;Xe-cores: 4;Ray Tracing: Yes;Max Resolution (HDMI): 4096 x 2304 @ 60Hz (HDMI 2.1 TMDS), 7680 x 4320 @ 60Hz (HDMI 2.1 FRL);Max Resolution (DP)‡: 7680 x 4320 @ 60Hz;Max Resolution (eDP - Integrated Flat Panel)‡: 3840 x 2400 @ 120Hz;DirectX* Support: 12;OpenGL* Support: 4.5;OpenCL* Support: 3;H.264 Hardware Encode/Decode: Yes;H.265 (HEVC) Hardware Encode/Decode Yes;AV1 Encode/Decode: Yes;VP9 Bitstream & Decoding: Yes;Intel® Quick Sync Video: Yes;# of Displays Supported: 4;Device ID: 0x7D67;Intel® Deep Learning Boost (Intel® DL Boost) on GPU: Yes;AI Software Frameworks Supported by GPU: OpenVINO™, WindowsML, DirectML, ONNX RT, WebGPU
Manufacturer Intel
Socket FCLGA1851
Number of cores Total Cores: 20;# of Performance-cores: 8;# of Efficient-cores: 12
Threads 20
Frequency Max Turbo Frequency: 5.5 GHz;Intel® Turbo Boost Max Technology 3.0 Frequency: 5.5 GHz;Performance-core Max Turbo Frequency: 5.4 GHz;Efficient-core Max Turbo Frequency: 4.6 GHz;Performance-core Base Frequency: 3.9 GHz;Efficient-core Base Frequency: 3.3 GHz
Cache Cache: 30 MB Intel® Smart Cache;Total L2 Cache: 36 MB
Memory Specifications Max Memory Size (dependent on memory type): 256 GB;Memory Types: Up to DDR5 6400 MT/s;Maximum Memory Speed: 6400 MHz;Max # of Memory Channels: 2;ECC Memory Supported: Yes
